High Speed Stainless Steel Emulsifying Machine









Key attributes

Industry-specific attributes

Barrel Volume (L)

300-5000L

Max. Loading Volume (L)

5000 L

Other attributes

Mixer Type

Homogenizer

Material Processed

Chemicals, Food

Weight (KG)

1000 KG

Condition

New

Place of Origin

Zhejiang, China

Power (kW)

15 kW

Warranty

1 Year

Key Selling Points

Flexible Manufacturing

Applicable Industries

Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Food Shop, Food & Beverage Shops

Showroom Location

Viet Nam, Nigeria, Malaysia

Marketing Type

Ordinary Product

Machinery Test Report

Provided

Video outgoing-inspection

Provided

Warranty of core components

1 Year

Core Components

Motor, Bearing

Range of Spindle Speed(r.p.m)

1400 - 2840 r.p.m

Max. Loading Capacity

5000L

Material

SUS304, SUS304L, SUS316, SUS316L

Product Type

Emulsifier

Application

Liquid with Suspended Solids

Additional Capabilities

Milling

Brand Name

VINCE

Voltage

220V/380V

Dimension(L*W*H)

Custom Made

After-sales Service Provided

Engineers available to service machinery overseas

Processing Types

Dairy Product

Processing

Emulsifier

Packaging and delivery

Selling Units:

Single item

Lead time

Quantity (pieces)	1 - 100	101 - 500	> 500
Lead time (days)	20	30	To be negotiated

Customization

Customized logo

Min. order: 1

Customized packaging

Min. order: 1

Graphic customization

Min. order: 1

Overview

High Speed Stainless Steel Emulsifying Machine

Product Description

Emulsifier, emulsifier machine, emulsifying machine

Primary functions:
The RH series of intermittent type high-shearing homogenization emulsion machine are high-powered stirring systems. Lower part has particular stator-rotor structure to make the material be high-shearing dispersed ,homogenized and emulsified intensively .Middle has high speed dispersed propeller-blade to assist with blending and homogenization.Upside has liquid flow under press type dispersed propeller-blade to control flow fluid effectively and process more thoroughly .
The equipment is applicable to blending, dispersing, homogenization and emulsification of fluid liquid material.

Application scope:
Food industry: edible coloring matter, chocolate coating, filling food, syrup, flavoring, various additive, etc;
Dairy products industry: ointment, lotion, cream, various vitamin, etc
Adhesive industry: rubber liquor, polyester sulfured, silicone, hot-melt adhesive, polyurethane, etc.

Technical Parameters:

Volume	300L	400L	500L	600L	800L	1000L	1500L	2000L	3000L
Tank diameter(mm)	Φ800	Φ800	Φ900	Φ1000	Φ1000	Φ1000	Φ1200	Φ1300	Φ1600
Tank height(mm)	600	800	800	800	1000	1220	1220	1500	1500
Motor power(kw)	0.55	0.55	0.75	0.75	0.75	0.75	1.5	2.2	3
Mixing speed(rpm)	1400/2800rpm
Working pressure	inner ≤0.1Mpa jacket 0.2MPa
Working temperature	inner<120°C
Basic valve	Sanitary manhole,cleaning ball,safety power,pressure meter
