High Quality Stainless Steel Sanitary Product Pump









Key attributes

Industry-specific attributes

Application

Food and Beverage Industry

Pressure

lifting pressure

Voltage

can be customized

Other attributes

Customized support

OEM

Place of Origin

Zhejiang, China

Power Source

Electric

Structure

Single-stage Pump

Warranty

3 years

Brand Name

VINCE

Outlet Size

38-63mm

Power

0.37-5KW

Theory

Centrifugal Pump

Usage

water, milk, juice, and other liquid

Application

delivery of milk,water, wine, pharmaceutical, chemical liquid

Packaging and delivery

Selling Units:

Single item

Single package size:

48X40X35 cm

Single gross weight:

30.000 kg

Lead time

Quantity (pieces)	1 - 100	101 - 500	> 500
Lead time (days)	20	30	To be negotiated

Customization

Customized logo

Min. order: 10

Customized packaging

Min. order: 10

Graphic customization

Min. order: 10

Overview

High Quality Stainless Steel Sanitary Pump

Product Description

Stainless Steel Cow Milk pump

1,Material:SS304/SS316L

2,Connection:clamp/thread/flange

3.high efficient energy saving

Stainless steel Sanitary pump /Centrifugal Pump/milk pump/beverage pump/beer pump/soy bean pump

1.Application

1	milk/juice/soy bean/drinks
2	aIcohol
3	foodstuff chemical
4	beverage to deliver Iiquid in smaII flow
5	high pressure filtering

2. Product details

Working Principle:	Centrifugal
Main applications:	Chemical, food, water
Driver:	Electric motor
Max.permissible fluid temperature:	100°C(212°F)
Installation position:	Horizontal
Casing/Inner parts material:	Stainless Steel/Stainless steel
Maximum viscosity:	5X104C.S.T
Maximum drive rating:	37KW(50HP)
Maximum caliber:	159mm(6 1/4inch)
Maximum discharge-side pressure:	0.6MPa(6bar)
Maximum head:	60m(196.8ft)
Flow rate range:	3-200m3/h(13.2-880US.GPM)

3.Selection Instructions

* Operating temperature: -20 - 150 º C(maximum sterilization temperature of 180 º C)

* Working environment and the media: To determine whether proof.

* Working conditions: Lobe pump is self-priming type, speed control can be mechanical control or frequency control options.

* Pump Material: 316L and 304 according to requirements of selected medium.

* Sealing materials: Standard rubber ring is silicone rubber. According to media select Viton, EPDM, PTFE, NBR. Standard mechanical seal is silicon carbide - hard alloy, according to media select graphite - silicon carbide, graphite - ceramics, etc.

* Suction connection: Standard quick clamps, upon request, select the pipe thread, flange, DIN standard, welding and so on.

4.Parameters

Model(Model)	Motor Power (kw)	Flow Rate(m³/h) Flow	Head (m) Pump Head	Inlet (mm) Imlet Dim	Outlet (mm) Outlet Dim
sanitary stainless steel sanitary centrifugal pump transfer milk beer beverage pump	0.75	3	15	38	32
RM03-20-1.1	1.1	3	20	38	32
RM05-24-1.5	1.5	5	24	51	38
RM05-32-2.2	2.2	5	32	51	38
RM10-24-2.2	2.2	10	24	51	38
RM10-32-3.0	3.0	10	32	51	38
RM15-24-3.0	3.0	15	24	51	38
RM20-24-4.0	4.0	20	24	51	51
RM20-35-5.5	5.5	20	35	63	51
RM30-24-5.5	5.5	30	24	63	51
RM30-35-7.5	7.5	30	35	63	51
RM40-24-7.5	7.5	40	24	76	63
RM50-24-7.5	7.5	50	24	76	63
RM50-24-11	11	50	24	76	63
